Ultimate Series Attic Ladder Wide – 2.81-3.075 x 700mm KASW08W
Kimberley Wide Ultimate Series Attic Ladders make accessing your roof space safe and easy. The ladder is neatly tucked away when not in use and opens effortlessly when required. Made from heavy duty aluminium extrusion the ladder is supplied fully assembled ready to install. wide series ladders are 150mm wider than regular Ultimate Series which is perfect when lifting a large object into the attic.
![](https://atticladdersandfloorsqld.com.au/wp-content/uploads/2023/12/sup-grade-door-panel2-1.png)
![](https://atticladdersandfloorsqld.com.au/wp-content/uploads/2023/12/high-strength-construction2.png)
![](https://atticladdersandfloorsqld.com.au/wp-content/uploads/2023/12/smooth-gas-strut-operation2-1-1.png)
Description
Specs
Brochure
Assembly Instructions
Description
Description
- Suitable for residential or commercial applications
- Easy to install. Ladder is height adjustable – no cutting of legs required
- Soft close, smooth gas strut operation
- No bulky springs doesn’t slam when closed
- High strength construction
- Superior grade 9.5mm thick laminated MDF door panel ready for painting
- Includes easy hang straps to make installation faster and easier
- Heavy duty aluminium extrusions for added strength
- Aluminium steps are serrated to resist slipping
- Complete with handrail (left handed available on request)
- Insulated door helps reduce energy costs/heat transfer
- Incorporated door seal to minimise drafts and dust
- Ladder comes fully assembled
- Injection moulded non slip EVA feet
- Larger spacing between steps and door for safer footing, even spacing including the first
Specs
Specs
Nominal Frame Size: 700 x 1300mm
Ceiling Height range: 2810 – 3075mm
Landing Space: 1310 – 1822mm
Projection: 1704 – 1922mm
Step: 80D x 455W x 40H mm
Side Rail: 80 x 20mm
Door Panel: 682 x 1273mm
Load Capacity: 150kg
