Ultimate Series Attic Ladder – 3.07-3.36m x 550mm KASW09a
Description
Specs
Brochure
Assembly Instructions
Description
Description
- Suitable for residential or commercial applications
- Easy to install. Ladder is height adjustable – no cutting of legs required
- Soft close, smooth gas strut operation
- No bulky springs doesn’t slam when closed
- High strength construction
- Fits standard 600mm ceiling joist centres
- Superior grade 9.5mm thick laminated MDF door panel ready for painting
- Includes easy hang straps to make installation faster and easier
- Heavy duty aluminium extrusions for added strength
- Aluminium steps are serrated to resist slipping
- Complete with handrail (left handed available on request)
- Insulated door helps reduce energy costs/heat transfer
- Incorporated door seal to minimise drafts and dust
- Ladder comes fully assembled
- Injection moulded non slip EVA feet
- Larger spacing between steps and door for safer footing, even spacing including the first
Specs
Specs
Nominal Frame Size: 550 x 1500mm
Ceiling Height range: 3070 – 3360mm
Landing Space: 1412 – 1972mm
Projection: 1917 – 2125mm
Step: 80D x 306W x 40H mm
Side Rail: 80 x 20mm
Door Panel: 535 x 1473mm
Load Capacity: 150kg
Brochure
Brochure
Assembly Instructions
