Deluxe Aluminium Attic Ladder – 2.7-3.05m Ceilings. 1200 x 530mm frame KASW46
*This Product now has an updated door and appears different to the picture*
Kimberley Deluxe Attic Ladders make accessing your roof space safe and easy. The ladder is neatly tucked away when not in use and opens effortlessly when required. Made from strong aluminium extrusion with heavy duty spring opening system, the ladder is supplied fully assembled ready to install.
Description
Specs
Brochure
Assembly Instructions
Description
Description
- Designed, engineered and made in Australia
- Adjustable tension heavy duty spring mechanism
- Kit includes easy reach extendable pole with hook – open the ladder safely at floor level
- Easy to install
- Ladder is height adjustable
- High strength construction
- Fits standard 600mm ceiling joist centres
- Includes easy hang straps to make installation faster and easier
- Aluminium steps are serrated to resist slipping
- Complete with handrail (right hand only)
- Ladder comes fully assembled
- Injection moulded non slip EVA feet
- For residential applications only
- Suits 2700-3050 ceiling height
Specs
Specs
Nominal Frame Size: 530 x 1300mm
Ceiling Height Range: 2700-3050mm
Landing Space: 1550-1750mm
Projection: 1900mm
Step: 80D x 340W x 20H mm
Side Rail: 80 x 20mm
Door Panel: 510 x 1280mm
Load Capacity: 135kg
Note : This product is made to order and should be despatched approximately two days after your order is confirmed.
