SELLWOOD PN30– 2.25-3.05m Nominal frame size 550-1280
The original Sellwood PN30 Attic Ladder is suitable for residential use for ceiling heights 2250mmm – 3050mm, common in homes built since the 1920s. They are most often used to access storage space in the attic. Fully preassembled, complete with an insulated, pre-finished white melamine lid
Description
Specs
Brochure
Assembly Instructions
Description
The original Sellwood PN30 Attic Ladder is suitable for residential use for ceiling heights 2250mmm – 3050mm, common in homes built since the 1920s. They are most often used to access storage space in the attic.
The Sellwood PN30 Attic Ladder is packed full of amazing features and benefits:
Easy to use
Sellwood’s unique spring system takes the full weight of the attic ladder into the ceiling, effortlessly lifting the ladder up into its frame, without the need for pushing or latching.
Built tough
Sellwood attic ladders use high quality, heavy duty steel hardware, ensuring they outlast cheaper imported brands. Sellwood’s unique main hinge provides superior weight distribution, adding strength, integrity and durability to the ladder.
Easy to install
Sellwood attic ladders come fully preassembled, complete with an insulated, pre-finished white melamine lid.
NZ Design
Sellwood attic ladders are designed in New Zealand. You can have confidence in your residential 15 Year Warranty, as you will have Sellwood’s full service and support, nationwide.
Specs
Specs
| Ceiling Heights | 2250mm – 3050mm |
|---|---|
| Opening Required | 1300mm x 560mm |
| Max Load | 200kg |
| Angle | 68° |
| Material | Timber |
| Ladder Width | 380mm |
| Landing Space | 1095mm – 1414mm |
| Projection | 1770mm |
| Handrail | Yes |
| Uses | Residential |
Brochure
SELLWOOD Attic Ladder Brochure
Assembly Instructions
Assembly Instructions
INSTALLATION INSTRUCTIONS
